Price 14700.0 INR/ Number

MOQ : 1 Number

MD290T3.7G/5.5P-INT AC Drive, Three Phase, 380 to 480V, 3.7/5.5kw - Inovance Ac Drive Specification

  • Product Type
  • VFD
  • Application
  • Industrial Machinerry
  • Color
  • Gray or Black
  • Usage & Applications
  • Industrial Machinerry
  • Weight
  • 3.3 Kilograms (kg)
  • Warranty
  • 1 Year
  • Phase
  • 3 Phase
  • Material
  • Polycarbonate


MD290T3.7G/5.5P-INT AC Drive, Three Phase, 380 to 480V, 3.7/5.5kw - Inovance Ac Drive Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 24 Hours


About MD290T3.7G/5.5P-INT AC Drive, Three Phase, 380 to 480V, 3.7/5.5kw - Inovance Ac Drive

The Inovance MD290T3.7G/5.5P-INT is a three-phase variable-frequency AC drive engineered for general-purpose open-loop industrial speed and torque regulations. [1]
Core Functional Capabilities
  • Dual-Rating Platform: Regulates standard three-phase AC asynchronous induction motors with a heavy-duty/normal-duty split footprint.
  • Heavy Duty Rating (G): Operates continuous automation loads up to 3.7 kW (5 HP) with 150% overload capacity for 60 seconds.
  • Normal Duty Rating (P): Drives variable-torque applications (such as industrial fans or centrifugal pumps) up to 5.5 kW (7.5 HP) with 110% overload threshold for 60 seconds.
  • Control Features: Employs open-loop V/F control backed by automated torque boosting, automatic slip compensation, and four independent programmable S-ramps.
  • Dynamic Braking: Equipped with an integrated, built-in braking unit to connect an external braking resistor directly for high-inertia deceleration. [1, 2, 3, 5]
Weight & Engineering Dimensions
This physical rating scales into the T3 Frame Size engineering layout. [1, 2]
The exact frame dimensions converted to inches and dry weight include: [1, 2]
  • Height: 9.84 inches (250 mm)
  • Width: 5.51 inches (140 mm)
  • Depth (Length): 6.69 inches (170 mm)
  • Total Operational Weight: 7.28 lbs (3.3 kg) [1]
