MD310T0.7B - 1HP - MD310 - 3 Phase - Inovance Ac Drive

Name: MD310T0.7B - 1HP - MD310 - 3 Phase - Inovance Ac Drive
Brand: Corbital Enterprise
Price: 7800.0 INR
Availability: InStock

Price 7800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MD310T0.7B - 1HP - MD310 - 3 Phase - Inovance Ac Drive Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
1.1 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

MD310T0.7B - 1HP - MD310 - 3 Phase - Inovance Ac Drive Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MD310T0.7B - 1HP - MD310 - 3 Phase - Inovance Ac Drive

The Inovance MD310T0.7B is the 1 HP (0.75 kW) high-performance variant of the MD310 series. It is designed for three-phase 400V power and offers more sophisticated motor control and communication options than the MD200 series. [1, 2, 3]

Dimensions & Weight

The MD310 uses a slightly wider, shorter frame compared to the "book-style" MD200.

Specification	Metric Value	Inch Value (Approx.)
Height	130 mm	5.12 in
Width	103 mm	4.06 in
Depth	151 mm	5.94 in
Weight	1.1 kg	2.43 lbs

Technical Specifications

Rated Power: 0.75 kW (1 HP).
Input Voltage: 3-Phase 380 V to 480 VAC.
Rated Output Current: 2.1 A.
Overload Capacity: 150% for 60 seconds; 180% for 2 seconds.
Braking: Includes a built-in dynamic braking unit (chopper). [1, 2, 3, 4, 5]

Key Functions

Performance: Features Sensorless Vector Control (SVC) and V/F control, providing high torque even at low speeds (150% torque at 0.5 Hz).
Flexible I/O: Comes with 5 digital inputs, 2 analog inputs, 1 high-speed pulse input, 1 relay output, and 1 analog output.
Connectivity: Supports standard Modbus-RTU and CANlink, with the ability to add expansion cards for Profibus-DP, CANopen, or additional I/O.
Energy Savings: Includes an automatic energy-saving function that optimizes the V/F curve based on the load.
