MD5204T315S-INT AC Drive, Three Phase, 380V to 480V,315kw - Inovance Ac Drive

Price 556800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MD5204T315S-INT AC Drive, Three Phase, 380V to 480V,315kw - Inovance Ac Drive Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Grey And Black

Weight
185 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

MD5204T315S-INT AC Drive, Three Phase, 380V to 480V,315kw - Inovance Ac Drive Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MD5204T315S-INT AC Drive, Three Phase, 380V to 480V,315kw - Inovance Ac Drive

The Inovance MD520 315 kW AC Drive (Model: MD5204T315S-INT) is a high-power, industrial vector variable frequency drive (VFD). This system operates at critical manufacturing capacities, safely regulating heavy-inertia three-phase electric motors.

According to official Inovance Technical Manuals, this 315 kW capacity model moves into the extra-large T12 frame size footprint to facilitate robust heat dissipation and handle significant operational current peaks. [1]

Device Measurements (T12 Frame Size)

The physical chassis dimension layouts converted from metric engineering metrics are:

Height (Total Length): 55.31 inches (\(1405\text{ mm}\))
Width: 15.75 inches (\(400\text{ mm}\))
Depth (Thickness): 21.46 inches (\(545\text{ mm}\))
Net Weight: 407.86 lbs (\(185.0\text{ kg}\)) [1]

Cabinet Backplate Mounting Layout

For robust floor or internal enclosure panel anchoring, apply these precise centerline parameters:

Horizontal Pitch Spacing: 9.45 inches (\(240\text{ mm}\))
Vertical Pitch Spacing: 50.39 inches (\(1280\text{ mm}\))
Mounting Fixing Bolt Hole Size: 0.63 inches (Requires heavy M16 bolts) [1]

Electrical & System Performance Specifications

Specification Metric [1, 2, 3, 4, 5]	Engineering Data Value
Manufacturer	Inovance Technology
Input Phase / Line Voltage	Three Phase, 380 V AC to 480 V AC (-15% to +10%)
Heavy Duty Power (HD)	315 kW (420 HP)
Normal Duty Power (ND)	355 kW (475 HP)
Rated Output Current (HD)	585 A
Rated Output Current (ND)	650 A
Overload Capacity Profile	Heavy Duty: 150% for 60s / Normal Duty: 110% for 60s
Output Frequency Spectrum	0 Hz to 599 Hz
Enclosure Protection Class	IP00 (Standard industrial chassis version for T12)

System Architecture & Protections

Dynamic Braking Layout: Requires an external braking configuration consisting of three parallel units (Model: MDBUN-200-5T x3) to safely suppress regenerative voltage loops during high-inertia deceleration. [1]
Harmonic Distortion Mitigation: Standard design integrates a built-in internal DC reactor to control grid harmonics and satisfy IEC line requirements. [1]
Atmospheric Resilience: Built with premium 3C3 and 3S2 level conformal coatings over internal PCBs to completely isolate electronics from dampness and conductive workshop dust. [1]
Functional Safety Integration: Equipped with standard dual-channel hardware Safe Torque Off (STO) terminals certified directly to SIL3 PL e protection standards. [1, 2, 3]

Please specify if you need the required input line fuse ratings for your electrical cabinet design, or if you need help planning minimum enclosure air clearances for heat management.
