SE3-043-5.5K Shihlin AC Drive 440V

Price 23200.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SE3-043-5.5K Shihlin AC Drive 440V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Usage & Applications
Industrial Machinerry

Weight
3.9 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SE3-043-5.5K Shihlin AC Drive 440V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SE3-043-5.5K Shihlin AC Drive 440V

The Shihlin SE3-043-5.5K is a 440V class, high-performance AC drive with a power rating of 5.5 kW (7.5 HP). It belongs to the Frame C category of the SE3 series, designed to handle larger industrial loads with advanced cooling and a built-in RFI filter.

Dimensions and Weight

This model uses the Frame C enclosure, which is significantly larger and heavier than the previously discussed 3.7 kW (Frame B) model to accommodate the increased power capacity and cooling requirements. [1, 2]

Dimension [1, 2, 3, 4]	Metric (mm/kg)	Imperial (inches/lbs)
Height (H)	270.0 mm	10.63 inches
Width (W)	141.0 mm	5.55 inches
Length/Depth (D)	185.0 mm	7.28 inches
Weight	3.9 kg	8.60 lbs
(Dimensions sourced from Amazen and official manuals)

Key Specifications

Rated Power: 5.5 kW (7.5 HP).
Input Voltage: 3-Phase 380480V AC.
Rated Output Current:
- Heavy Duty (HD): 12.0A.
- Normal Duty (ND): 15.7A.
Cooling Method: Forced Air Cooling (equipped with a high-efficiency internal fan).
Output Frequency: Standard 0.1 to 599 Hz; high-speed models support up to 1500 Hz. [1, 2, 3, 4, 5, 6, 7, 8]

Performance Features

Dual-Rating: Supports both Induction Motors (IM) and Permanent Magnet Motors (PM).
Control Modes: V/F, Sensorless Vector Control (SVC), and Optional Closed-loop Vector Control (FVC) with an expansion card.
Protection: Advanced overload endurance (150% for 60s in HD mode) and environment protection (IP20 rating).
Communication: Built-in RS-485 and one expansion card slot for protocols like Profibus, EtherCAT, or CANopen. [1, 2, 3]
