VSM48-004-20CNB - Crompton VFD - VSM48 - 1.5 kW / 2HP 3-Phase 380-480V

Name: VSM48-004-20CNB - Crompton VFD - VSM48 - 1.5 kW / 2HP 3-Phase 380-480V
Brand: Corbital Enterprise
Price: 9200.0 INR
Availability: InStock

Price 9200.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSM48-004-20CNB - Crompton VFD - VSM48 - 1.5 kW / 2HP 3-Phase 380-480V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Weight
1.1 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSM48-004-20CNB - Crompton VFD - VSM48 - 1.5 kW / 2HP 3-Phase 380-480V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSM48-004-20CNB - Crompton VFD - VSM48 - 1.5 kW / 2HP 3-Phase 380-480V

The Crompton Greaves Emotron VSM48-004-20CNB is a compact, high-performance general-purpose Variable Frequency Drive (VFD) from the Emotron VSM series. It is designed for standard 3-phase industrial power grids, accepting a 380V to 480V AC input to provide precise speed and torque control for both traditional 3-phase induction motors and high-efficiency permanent magnet synchronous motors (PMSM) up to 2 HP (1.5 kW). [1, 2, 3, 4]

Physical Dimensions (Inches & Pounds)

The VSM48-004 utilizes a highly compact footprint, making it ideal for tight spaces inside industrial electrical panels: [1]

Weight: 2.43 lbs (1.1 kg)
Height: 5.91 inches (150 mm)
Width: 2.95 inches (75 mm)
Depth (Thickness): 4.72 inches (120 mm)

Mounting Dimensions

For backplate layout design or drilling templates inside your enclosure, use these measurements:

Mounting Height (H1): 5.51 inches (140 mm)
Mounting Width (W1): 2.56 inches (65 mm)
Installation Aperture (Screw Hole Diameter): 0.18 inches (4.5 mm)

Technical Specifications

This 2 HP drive is engineered with the following electrical and communication parameters:

Feature [1, 2, 3, 4, 5]	Specification
Model Number	VSM48-004-20CNB / 20CEB
Motor Power Rating	1.5 kW / 2 HP
Input Supply Power	3-Phase 380V to 480V AC (20%), 50/60 Hz
Rated Output Current	4.2 Amps continuous
Overload Capacity	150% heavy-duty for 60 seconds / 200% for 1 second
Protection Rating	IP20 (Must be deployed inside a protected electrical cabinet)
Brake Chopper	Integrated / Built-in as standard
Control Logic Interface	5 Digital Inputs (DI), 2 Analog Inputs (AI), 1 Relay Output, 1 Digital Output
EMC Filter	Built-in C3 Class filter to reduce high-frequency electrical noise
Communication Terminal	Built-in RS-485 Modbus RTU protocol interface

Core Applications

This drive excels at handling constant-torque and variable-torque machinery setups where precise control is required:

Packaging & Textiles: Small wrapping machines, spinning frames, and tension control systems.
Conveyors & Feeders: Factory assembly lines, material handling systems, and part feeders.
Pumps & Fans: Small booster pumps, localized industrial extraction fans, and HVAC dampers.
