VSR48-013 - Crompton VFD - 5.5 kW / 7.5HP 3-Phase 380V Solar

Name: VSR48-013 - Crompton VFD - 5.5 kW / 7.5HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 20000.0 INR
Availability: InStock

Price 20000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSR48-013 - Crompton VFD - 5.5 kW / 7.5HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
2.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSR48-013 - Crompton VFD - 5.5 kW / 7.5HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSR48-013 - Crompton VFD - 5.5 kW / 7.5HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSR48-013 is a high-performance 7.5 HP (5.5 kW) three-phase solar Variable Frequency Drive (VFD) designed for heavy agricultural irrigation and large-scale water pumping. Moving up from the 3 HP and 5 HP models, this drive uses a larger physical chassis (Frame Size VSR3) to handle increased current demands. [1, 2, 3, 4, 5]

Physical Dimensions (Inches & Pounds)

Unlike the smaller 3 HP and 5 HP units, the VSR48-013 features an expanded footprint: [1, 2, 3, 4]

Weight: 5.51 lbs (2.5 kg)
Height: 7.35 inches (186.6 mm)
Width: 4.59 inches (116.6 mm)
Depth (Thickness): 6.89 inches (175 mm) [1, 2, 3]

Technical & Solar Array Specifications

The upgraded electrical limits require a more robust solar panel configuration to maintain peak efficiency: [1, 2]

Feature [, 2, 3, 4, 5]	Specification
Model Number	VSR48-013-20CEB
Power Rating	5.5 kW / 7.5 HP
Rated Output Current	13.0 Amps
Maximum Input DC Current	20.0 Amps
Recommended Solar Array Power	Up to 8.9 kWp
Recommended Voc Range	500V to 700V DC
Optimal MPPT Voltage Range	450V to 600V DC
Maximum Input DC Voltage	800V DC
