VSR48-038 - Crompton VFD - 18.5kW / 25HP 3-Phase 380V Solar

Name: VSR48-038 - Crompton VFD - 18.5kW / 25HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 29300.0 INR
Availability: InStock

Price 29300.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSR48-038 - Crompton VFD - 18.5kW / 25HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
6.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSR48-038 - Crompton VFD - 18.5kW / 25HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSR48-038 - Crompton VFD - 18.5kW / 25HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSR48-038 is an industrial-grade 25 HP (18.5 kW) three-phase solar Variable Frequency Drive (VFD). Engineered to operate large-scale setups, this heavy-duty system is heavily relied on for high-yield community drinking water projects, commercial irrigation fields, deep tube wells, and high-torque machinery like industrial flour mills. [1, 2]

Physical Dimensions (Inches & Pounds)

To properly insulate and cool the 25 HP power transistors, this model uses a wider, block-style industrial housing chassis:

Weight: 14.33 lbs (6.5 kg)
Height: 10.08 inches (256 mm)
Width: 7.32 inches (186 mm)
Depth (Thickness): 7.68 inches (195 mm) [, 2, 3, 4]

Technical & Solar Array Specifications

To feed this drive's continuous 38 Amp load capacity without system tripping, the solar array must be engineered to match these tolerances:

Feature [1, 2, 3, 5, 6]	Specification
Model Number	VSR48-038-20CEB / 20CNB
Power Rating	18.5 kW / 25 HP
Rated Output Current	37.0 to 38.0 Amps
Maximum Input DC Current	53.0 to 60.0 Amps
Recommended Solar Array Power	26.0 to 27.5 kWp
Recommended Voc Range	600V to 700V DC
Optimal MPPT Voltage Range	450V to 600V DC
Maximum Input DC Voltage	800V DC
