VSRE48-004 - Crompton VFD - 1.5 kW / 2HP 3-Phase 380V Solar

Name: VSRE48-004 - Crompton VFD - 1.5 kW / 2HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 10000.0 INR
Availability: InStock

Price 10000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSRE48-004 - Crompton VFD - 1.5 kW / 2HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
1.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSRE48-004 - Crompton VFD - 1.5 kW / 2HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSRE48-004 - Crompton VFD - 1.5 kW / 2HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSRE48-004 is a heavy-duty 1.5 kW (2 HP) Solar Variable Frequency Drive (VFD) configured for a 3-phase 380V480V industrial grid backup or a high-voltage solar DC input. Because this 2 HP model shares the exact same high-voltage architecture as the 1 HP model, it remains on the Frame Size 2 (VSR2) enclosure platform. [1, 2, 3]

Physical Dimensions & Weight

The physical dimensions match the standard Frame 2 chassis precisely: [1]

Height: 173 mm (6.81 inches)
Width: 110 mm (4.33 inches)
Depth / Length: 135 mm (5.31 inches)
Total Weight: 1.5 kg (3.31 lbs) [1, 2, 3]

Mounting Dimensions (Center-to-Center Holes)

Mounting Hole Height (H1): 163 mm (6.42 inches)
Mounting Hole Width (W1): 100 mm (3.94 inches)
Installation Screw Diameter (d): 4.5 mm (0.18 inches) [1]

Technical & Electrical Sizing

While the outer dimensions match the 1 HP version, the internal electronics are scaled up to support higher current demands: [1]

Power Rating: 1.5 kW / 2 HP
Rated Output Current: 4.2 Amps (compared to 2.5A on the 1HP version)
Maximum Solar DC Input Voltage: 800V DC
Optimal MPPT Tracking Range: 450V to 600V DC
Recommended Solar Array Power: 2.25 kWp (Kilowatt-peak) to ensure reliable pump start-up under varying cloud cover. [1, 2, 3, 4, 5]

Motor Performance Note

This drive is highly versatile and supports both standard 3-phase AC Induction Motors and high-efficiency Permanent Magnet Synchronous Motors (PMSM). When driving a PMSM pump, the advanced software logic enables maximum torque output at exceptionally low starting currents. [1, 2]
