VSRE48-009 - Crompton VFD - 3.7 kW / 5HP 3-Phase 380V Solar

Name: VSRE48-009 - Crompton VFD - 3.7 kW / 5HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 10100.0 INR
Availability: InStock

Price 10100.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSRE48-009 - Crompton VFD - 3.7 kW / 5HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Weight
1.5 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSRE48-009 - Crompton VFD - 3.7 kW / 5HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSRE48-009 - Crompton VFD - 3.7 kW / 5HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSRE48-009 is a heavy-duty 3.7 kW (5 HP) Solar Variable Frequency Drive (VFD) engineered to operate high-capacity, high-head water pumping networks. This model utilizes the slightly optimized Frame Size 2 (VSR2) enclosure chassis variant, keeping it highly compact while significantly boosting its internal electronic current capacity to drive robust 5 HP three-phase motors. [1, 2, 3]

Physical Dimensions & Weight

The physical housing measurements converted from standard industrial metric layouts are detailed below:

Dimension Attribute [1, 2]	Metric Specification	Imperial Specification (Inches)
Height (H)	171 mm	6.73 in
Width (W)	93 mm	3.66 in
Depth / Length (D)	130 mm	5.12 in
Total Net Weight	1.35 kg to 1.45 kg	2.97 lbs to 3.20 lbs

Electrical Sizing Specifications

Power Capacity: 3.7 kW / 5 HP
Rated Output Current: 9.5 Amps (Handles higher sustained mechanical loads for deep well irrigation)
Maximum Input DC Current: 18 Amps
Maximum Solar DC Input Voltage: 800V DC
Optimal MPPT Voltage Window: 450V to 600V DC
Recommended Solar Array Power: 5.5 kWp to 6.0 kWp (Kilowatt-peak array size to support peak flow rate) [1, 5]

Core Operational Features

Hybrid Energy Source Optimization: Capable of prioritizing direct solar DC power during peak daylight hours while automatically leaning on a secondary 3-Phase 380V480V AC grid backup or generator loop during severe cloud cover or nighttime cycles. [1]
99% Solar Tracking Efficiency: Integrates an advanced, self-adaptive Maximum Power Point Tracking (MPPT) engine to extract peak water volume out of the solar panels even in low-radiance weather. [1, 2]
Advanced Motor Profiling: Full firmware integration to easily pair with standard AC Induction Motors (IM) or high-torque, energy-efficient Permanent Magnet Synchronous Motors (PMSM). [1]
Comprehensive Protective Suite: Built-in safeguards including pump dry-run mitigation, tank overflow control integration, output phase loss, over-current trip, and lightning protection. [1, 2]
