VSX48-006-20CEB - Crompton VFD - VSX48 - 2.2 kW / 3HP 3-Phase 380-480V

Name: VSX48-006-20CEB - Crompton VFD - VSX48 - 2.2 kW / 3HP 3-Phase 380-480V
Brand: Corbital Enterprise
Price: 15000.0 INR
Availability: InStock

Price 15000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSX48-006-20CEB - Crompton VFD - VSX48 - 2.2 kW / 3HP 3-Phase 380-480V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Weight
1.5 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSX48-006-20CEB - Crompton VFD - VSX48 - 2.2 kW / 3HP 3-Phase 380-480V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSX48-006-20CEB - Crompton VFD - VSX48 - 2.2 kW / 3HP 3-Phase 380-480V

The Crompton Greaves Emotron VSX48-006-20CEB is a premium, high-performance 3 HP (2.2 kW) three-phase general-purpose Variable Frequency Drive (VFD) from the advanced Emotron VSX series. It operates on industrial 3-phase utility or generator grids (380V480V AC) and uses advanced sensorless vector control to provide precise speed regulation for both AC induction motors and permanent magnet synchronous motors (PMSM). [1, 2, 3, 4, 5]

Unlike simpler entry-level series, the premium VSX48 line features an integrated graphical LCD display with real-time oscilloscope tracking alongside highly flexible on-board PLC logic functions. [, 2, 3]

Physical Dimensions (Inches & Pounds)

The exact physical parameters converted to imperial units for enclosure layout optimization are:

Weight: 3.20 lbs (1.45 kg Net / 1.5 kg frame)
Height: 7.87 inches (200 mm)
Width: 3.15 inches (80 mm)
Depth (Thickness): 6.69 inches (170 mm) [1, 3, 4, 5]

Technical Specifications

The standard electrical limits and communication attributes engineered into this 3 HP variant include:

Feature [, 2, 3, 4, 5]	Specification
Model Number	VSX48-006-20CEB
Motor Power Rating	2.2 kW / 3 HP
Input Supply Power	3-Phase 380V to 480V AC (\(\pm20\%\) fluctuation capacity), 50/60 Hz
Rated Output Current	5.5 Amps continuous
Peak Overload Capacity	150% heavy-duty for 60s / 200% for 1 second
Enclosure Rating	IP20 (Requires clean, moisture-controlled cabinet placement)
Noise Protection	Integrated C3 Class EMC Filter for electromagnetic suppression
I/O Interface	High-speed tracking pulse inputs up to 100 kHz
Diagnostic Terminal	Compatible with EmoWizard configuration software tool

Core Functionality & Applications

The drive utilizes tropicalized conformal-coated internal circuit boards and a completely separated air duct design to protect vulnerable electronic components from extreme heat or manufacturing debris. It excels in high-torque, precise industrial environments: [, 2, 3]

Heavy Industrial Machinery: High-torque crushers, material extruders, crane hoists, and heavy product feeders.
Fluid & Air Processing: Multi-pump commercial water arrays, cooling towers, and localized extraction blowers. [1]
