ECMA-CA0807SS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000

Name: ECMA-CA0807SS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000
Brand: Corbital Enterprise
Price: 51000.0 INR
Availability: InStock

Price 51000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-CA0807SS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
4.22 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-CA0807SS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-CA0807SS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000

The Delta ECMA-CA0807SS functions as a high-precision actuator for industrial automation, primarily used to control position, speed, and torque with extreme accuracy.

Core Functions

Precision Positioning: Equipped with a 20-bit incremental encoder (offering 1,280,000 pulses per revolution) or a 17-bit absolute encoder, ensuring the motor can reach exact coordinates for tasks like CNC machining and robotics.
Static Braking (Safety): The "SS" model includes a built-in electromagnetic brake. Its function is to hold the load in place when power is removed, preventing vertical axes from falling or machinery from shifting during an emergency stop.
Dynamic Motion Control: When paired with an ASDA-A2 drive, it supports advanced functions like:
- Electronic Cam (E-CAM): Used for rotary cut-offs, flying shears, and synchronized motion.
- Vibration Suppression: Built-in filters automatically minimize mechanical vibration at machine edges.
- Full Closed-loop Control: Can read external signals to compensate for mechanical backlash. [1, 2, 3, 4, 5, 6]

Common Applications

CNC Machinery: Accurate axis movement for milling and cutting.
Robotics & Packaging: High-speed, repeatable tasks requiring synchronized multi-axis movement.
Textile & Printing: Maintaining precise tension (torque mode) and speed. [1, 2, 3, 4]

The physical dimensions and weight for the Delta ECMA-CA0807SS (750W model with brake) are as follows:

Dimensions & Weight

Attribute [1, 2, 3, 4]	Measurement (Inches)	Measurement (Metric)
Total Length	6.61 in	168 mm
Height (Frame)	3.15 in	80 mm
Width (Frame)	3.15 in	80 mm
Shaft Diameter	0.748 in	19 mm
Shaft Length	1.378 in	35 mm
Net Weight	9.30 lbs	4.22 kg

Key Specifications

Frame Size: This motor uses a standard 80 mm square frame, which is larger than the 400W model.
Weight Detail: The 9.30 lb (4.22 kg) weight includes the integrated electromagnetic brake. Models without a brake are typically lighter, around 6.39 lbs (2.9 kg).
Mounting: The mounting hole spacing is approximately 3.54 inches (90 mm).
Power & Performance: Delivering 750W of power with a rated torque of 2.39 Nm and a rated speed of 3000 RPM. [1, 2, 3, 4, 5]
