ECMA-FA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

Name: ECMA-FA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500
Brand: Corbital Enterprise
Price: 91500.0 INR
Availability: InStock

Price 91500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-FA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
18.5 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ECMA-FA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-FA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

The Delta ECMA-FA1830RS is a high-power 3.0 kW servo motor from the ASDA-A2 series, specifically categorized as part of the Medium-High Inertia line. This design provides superior stability for very heavy loads, making it a preferred choice for large-scale CNC machinery and high-torque industrial automation. [1, 2]

The "RS" suffix indicates that this motor includes a keyway and oil seal but does not have a brake. [1]

Physical Specifications

This motor utilizes a large 180 mm frame to handle its high torque and power requirements. [1, 2]

Attribute [1, 2, 4]	Metric Value	Inches / US Units
Height (Frame)	180 mm	7.09 in
Width (Frame)	180 mm	7.09 in
Length (Body)	202.1 mm	7.96 in
Weight	18.5 kg	40.8 lbs

Key Technical Data

Precision Control: Features a 17-bit absolute encoder (131,072 pulses/rev), which allows the motor to retain its exact position even after power is lost, eliminating the need for homing.
Torque & Speed: Delivers a high rated torque of 19.1 Nm and a peak torque of up to 57.3 Nm at a rated speed of 1500 RPM.
Industrial Durability: Rated IP65 for resistance to dust and water splashes, ensuring reliable operation in harsh environments.
Power Input: 220 VAC, compatible with both single and three-phase power supplies.
