ECMA-LA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

Name: ECMA-LA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500
Brand: Corbital Enterprise
Price: 87400.0 INR
Availability: InStock

Price 87400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-LA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
18.5 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ECMA-LA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-LA1830RS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

The Delta ECMA-LA1830RS is a high-torque, 3000W (3kW) absolute-type servo motor. It belongs to the 400V ASDA-A2 series and is designed for heavy-duty industrial axes that require massive force and high motion stability. [1]

Dimensions & Weight

Attribute	Measurement (Inches)	Measurement (Metric)
Total Length	7.95 in	202 mm
Height (Frame)	7.09 in	180 mm
Width (Frame)	7.09 in	180 mm
Shaft Diameter	1.378 in	35 mm
Shaft Length	3.11 in	79 mm
Net Weight	40.78 lbs	18.5 kg

Key Specifications

Torque Performance: Delivers a rated torque of 19.1 Nm and can reach a peak torque of 57.3 Nm.
Inertia Class: Medium-High Inertia. This motor is specifically built to handle massive mechanical loads without the "vibration" or "jitter" seen in low-inertia models.
Absolute Encoder: Features a 17-bit absolute encoder. It tracks its physical position at all times, so the machine never needs to be "homed" after a power cut.
Voltage: 400V VAC (3-Phase), intended for large industrial power grids.
Brake Status: The "RS" suffix indicates this model is without a brake. It includes an oil seal and keyway for industrial durability.

The Delta ECMA-LA1830RS is a high-power, medium-high inertia servo motor from the 400V ASDA-A2 series. It is specifically designed for "High Torque, Low Speed" industrial applications where precision and load stability are critical.

Electrical & Performance Specifications
