GD10-2R2G-S2-B - INVT VFD 2.2 kW / 2HP 230V

Name: GD10-2R2G-S2-B - INVT VFD 2.2 kW / 2HP 230V
Brand: Corbital Enterprise
Price: 7200.0 INR
Availability: InStock

Price 7200.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD10-2R2G-S2-B - INVT VFD 2.2 kW / 2HP 230V Specification

Feature
V/f control

IP Rating
20

Humidity %
5% to 95%

Mounting Type
DIN-rail mounting

Product Type
VFD

Power Rating
220V (-15%) to 240V (+10%)

Application
Industrial Machinery

Color
Black

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Weight
2.86 Kilograms (kg)

Usage & Applications
Industrial Machinery

Warranty
1 Year

Phase
1 Phase

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Material
Plastic

Features
Modbus RS485

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

GD10-2R2G-S2-B - INVT VFD 2.2 kW / 2HP 230V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD10-2R2G-S2-B - INVT VFD 2.2 kW / 2HP 230V

Actually, there is a small correction to the power rating: the GD10-2R2G-S2-B is rated for 2.2 kW, which is equivalent to 3 HP, not 2 HP (the 1.5 kW model is 2 HP). It is the highest-capacity single-phase input drive in the compact GD10 mini-series.

Power	3 HP
Usage	for Industrial Machinery
Brand	INVT
Model Name/Number	GD10-2R2G-S2-B
Input Voltage	220 vac
Input Phase	1 - Phase

Key Specifications

Function: High-performance V/f control for speed and torque management. Features built-in PID, 16-step speed control, and Modbus RS485 for PLC integration.
Colour: Black.
Mounting Type: Wall-mounting or DIN-rail mounting.
Voltage: Single-phase 220V240V input; 3-phase 0220V output.
Current: Rated for 24A input and 10A output.
Humidity: 5% to 95% RH (non-condensing).
