MCDLN35SG - A6SG Panasonic A6 750W Driver

About MCDLN35SG - A6SG Panasonic A6 750W Driver

Electrical Specifications

• Series: MINAS A6SG
• Rated Motor Power: 750 W
• Supply Voltage: 200 V AC (single/3-phase)
• Output Current: 22 A class
• Control Modes: Position control (primary)
• Interface: Pulse input + RS232 / RS485 (Modbus)
• Frequency Response: 3.2 kHz

---

Control & Function Features

This driver is the control brain of the servo system, and its main functions are:

1. Position Control

• Converts pulse commands into exact motor position
• Used in CNC, robotics, indexing systems

2. Speed Control

• Maintains smooth rotation under changing load
• Automatically adjusts torque output

3. Torque Control (indirect mode)

• Limits or regulates motor force
• Protects mechanical system from overload

4. Closed-loop Feedback Control

• Reads encoder (23-bit high resolution)
• Continuously corrects position error in real time

---

Safety & System Features

• No STO safety function (A6SG basic variant)
• Auto tuning for easy setup
• Vibration suppression control
• 256 internal position memory blocks
• Dynamic braking support

---

Physical Size (In Inches)

• Height: 150 mm 5.91 in
• Width: 65 mm 2.56 in
• Depth: 170 mm 6.69 in
• Weight: 1.6 kg 3.5 lb

---

What it actually does (Simple)

This driver acts like the brain + power amplifier:

1. Takes motion command from PLC/CNC
2. Sends controlled power to motor
3. Reads encoder feedback
4. Corrects position instantly
5. Ensures smooth, accurate movement

---

Typical Applications

• CNC machines
• Industrial robots
• Packaging and filling machines
• Conveyor systems
• Automation lines

---

Simple One-Line Meaning

MCDLN35SG is a 750W Panasonic A6SG servo driver that precisely controls motor position, speed, and torque using real-time encoder feedback for industrial automation.

---

Key Difference (important for your set)

• SE: basic pulse control
• SG (this): adds RS232/RS485 communication
• SF: advanced + safety features
• NE: high-speed RTEX network system

  Function of Panasonic MCDLN35SG (A6SG 750W Servo Driver)

  This device is a servo drive (amplifier). Its main function is to control a 750W servo motor with precise motion, force, and speed using feedback from the motor encoder.

  ---

  Core Function

  It converts control signals from PLC/CNC into accurate electrical power for the servo motor, ensuring precise movement.

  ---

  What it does in practice

  1. Position Control

  • Moves motor to exact positions
  • Ensures repeatable accuracy for machines
  • Used in CNC axes, robots, indexing systems

  ---

  2. Speed Control

  • Maintains stable rotation speed (even under load changes)
  • Smooth acceleration and deceleration
  • Prevents speed fluctuation

  ---

  3. Torque Control

  • Controls motor force output
  • Protects machine from overload or sudden force spikes
  • Useful in pressing, winding, feeding systems

  ---

  4. Closed-Loop Feedback Control

  • Reads 23-bit encoder feedback from motor
  • Compares actual position vs command
  • Corrects errors in real time (milliseconds response)

  ---

  System Role

  In a servo system:

  • Motor = muscle
  • Driver (MCDLN35SG) = brain + power control
  • Encoder = eyes (feedback sensor)

  ---

  Additional Functions

  • Auto tuning (automatic gain adjustment)
  • Vibration suppression (smooth motion)
  • Multi-axis communication support (RS485/RS232)
  • 256 internal position programs (basic motion sequences)

  ---

  Where it is used

  • CNC machines
  • Industrial robots
  • Packaging machines
  • Conveyor automation
  • Pick-and-place systems

  ---

  Simple One-Line Meaning

  MCDLN35SG is a 750W servo driver that precisely controls motor position, speed, and torque using real-time feedback for accurate industrial motion.

Superior Performance and Durability

Crafted with high-quality aluminum and a reliable packing seal, the A6SG Panasonic Driver is built to endure challenging industrial settings. Its robust design ensures consistent performance, significantly minimizing downtime and maintenance needs.


Ideal for Industrial Automation

This 750W driver is specifically designed for industrial machinery, offering accurate control and motion precision. By operating on a three-phase power supply, the device can handle demanding automation tasks, optimizing productivity in manufacturing environments.


Reliable Warranty and Support

Every MCDLN35SG driver is supported by a 1-year warranty, providing users with assurance of quality and after-sales support. Suppliers, traders, and wholesalers can count on Panasonic's reputation for dependability and efficient service.
