MD310T7.5B - 10HP - MD310 - 3 Phase - Inovance Ac Drive

Name: MD310T7.5B - 10HP - MD310 - 3 Phase - Inovance Ac Drive
Brand: Corbital Enterprise
Price: 19700.0 INR
Availability: InStock

Price 19700.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MD310T7.5B - 10HP - MD310 - 3 Phase - Inovance Ac Drive Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
2.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

MD310T7.5B - 10HP - MD310 - 3 Phase - Inovance Ac Drive Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MD310T7.5B - 10HP - MD310 - 3 Phase - Inovance Ac Drive

The Inovance MD310T7.5B is a high-performance 10 HP (7.5 kW) 3-phase AC drive. This model uses the larger Frame Size 3 chassis to manage the increased current and heat of a 10 HP motor while maintaining the series' reputation for high torque and precision. [1, 2, 3]

Dimensions & Weight

As a Frame Size 3 unit, it has the same footprint as the 7.5 HP model, allowing for standardized panel layouts.

Specification	Metric Value	Inch Value (Approx.)
Height	234 mm	9.21 in
Width	140 mm	5.51 in
Depth	171 mm	6.73 in
Weight	2.5 kg	5.51 lbs

Key Technical Data

Rated Power: 7.5 kW (10 HP).
Rated Output Current: 17.0 A.
Input Voltage: 3-Phase 380 V to 480 VAC.
Overload Capacity: 150% for 60 seconds; 180% for 2 seconds.
Braking: Includes a built-in dynamic braking unit (Chopper) as standard. [1, 2, 3, 4, 5]

Functions & Features

Vector Performance: Uses Sensorless Vector Control (SVC) to provide 150% starting torque at 0.25 Hz, ideal for high-inertia starts.
Durability: PCBs feature a Class 3C3 conformal coating, offering superior protection against humidity and chemically active substances.
Connectivity: Standard Modbus-RTU and CANlink ports, with expansion slots available for PROFIBUS-DP or CANopen.
Flexible I/O: Equipped with 5 digital inputs (one supports 100 kHz pulse input) and 2 analog inputs (010 V or 420 mA).
