MD5204T75BS-INT AC Drive, Three Phase, 380V to 480V,75kw - Inovance Ac Drive

Price 121300.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MD5204T75BS-INT AC Drive, Three Phase, 380V to 480V,75kw - Inovance Ac Drive Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Grey And Black

Weight
51.5 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

MD5204T75BS-INT AC Drive, Three Phase, 380V to 480V,75kw - Inovance Ac Drive Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MD5204T75BS-INT AC Drive, Three Phase, 380V to 480V,75kw - Inovance Ac Drive

The MD5204T75BS-INT is a specific, high-performance configuration of the Inovance MD520 series. It is a three-phase, low-voltage Variable Frequency Drive (VFD) optimized for precise motor speed and torque regulation across heavy industrial applications. [1, 2]

Part Number Breakdown

MD520: High-performance universal VFD product line.
4T: Three-phase, 380V to 480V AC supply voltage rating.
75: 75 kW power rating for Heavy Duty (HD) operation.
B: Built-in dynamic braking unit.
S: Built-in DC reactor for harmonic mitigation.
INT: International variant compliant with European and global technical standards. [1, 2, 3, 4, 5]

Technical Specifications

Power Rating: 75 kW (Heavy Duty / HD) / 90 kW (Normal Duty / ND).
Overload Capacity: 150% for 60 seconds (HD) / 110% for 60 seconds (ND).
Rated Current: 150 A (HD) / 176 A (ND).
Input Voltage: 3-phase, 380 V AC to 480 V AC (10% fluctuations tolerated).
Output Frequency Range: 0 Hz to 599 Hz.
Motor Control Capabilities: Open-loop V/F, Sensorless Vector Control (SVC), and Closed-loop Flux Vector Control (FVC).
Compatible Motor Types: Three-phase AC asynchronous (induction) and Permanent Magnet (PM) synchronous motors.
Safety Integration: Built-in Safe Torque Off (STO) certified to SIL 3 / PL e levels. [1, 2, 3, 4, 5, 6, 7]

Operational Features

Built-in Protection: Equipped with an internal DC reactor to limit harmonics and a dynamic braking unit for regenerative energy management. [1, 2, 3, 4, 5]
Environmental Resilience: Conformal-coated PCBs rated for 3S2 and 3C3 environments protect internal components against moisture, dust, and corrosive gases. [1, 2]
Network Connectivity: Supports fieldbus communication modules including Modbus-RTU, PROFIBUS-DP, PROFINET, CANopen, and EtherCAT
