MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000

Name: MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000
Brand: Corbital Enterprise
Price: 21000.0 INR
Availability: InStock

Price 21000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000 Specification

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
1.1 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
24 Hours

About MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000

The

Panasonic MHMF5AZL1U2M

is a 50 W AC servo motor from the MINAS A6 series. While it shares the same power, torque, and RPM as the MSMF series you previously viewed, this model belongs to the High Inertia family, making it better suited for applications with larger mechanical loads that require steady, stable motion.

Core Functions

Stable Load Handling: Its High Inertia design provides a more stable response when driving mechanical systems with significant mass (like large lead screws or heavy rotary tables), preventing oscillations that might occur with low-inertia motors.
Pinpoint Positioning: Equipped with a 23-bit absolute encoder, it offers 8,388,608 pulses per revolution, enabling high-resolution control and eliminating the need for homing cycles.
Environmental Protection: It features an IP65 rating and a high-heat-resistant oil seal with a protective lip, making it durable against dust and oil in harsh factory settings.

Technical Specifications

Feature	Specification
Rated Output	50 W
Rated Torque	0.16 Nm
Rated Speed	3000 RPM (Max 6000 RPM)
Inertia Type	High Inertia
Encoder Type	23-bit Absolute
Brake Status	Without Holding Brake
Flange Size	40 mm sq.
Input Voltage	200 V (1-Phase/3-Phase)
Protection Class	IP65

Physical Dimensions & Weight (Imperial)

Weight: 2.43 lbs (1.1 kg)
Width/Height: 1.57 inches (40 mm)
Length (Excluding Shaft): 2.66 inches (67.5 mm)
Shaft Type: Key-way, threaded shaft.

The Panasonic MHMF5AZL1U2M is a high-performance High Inertia motor from the MINAS A6 series. While it has the same 50W power as the MSMF series, its internal design is balanced for stability rather than just raw speed.

Primary Functions

Mass Stability Control: Its primary function is to handle "heavy" mechanical loads (relative to its size). Because it has higher internal inertia, it acts as a stabilizer, preventing the motor from overshooting or vibrating when moving a large belt or a long lead screw.
Ultra-Precision Positioning: With its 23-bit absolute encoder, it functions with extreme resolution (8,388,608 pulses per revolution). This allows for microscopic movements required in semiconductor manufacturing or precision laboratory equipment.
Homing-Free Operation: It functions as an Absolute motor. It remembers its mechanical position even when the power is pulled, meaning your machine can start working immediately upon power-up without a "return to zero" sequence.
Load Suppression: It works with the A6 driver to automatically compensate for mechanical friction and "unbalanced" loads, ensuring the output speed remains perfectly constant even if the resistance changes.

Key Features of the A6 High Inertia Series

Reduced Cogging: This motor is designed to minimize "magnetic bumping" (cogging), which allows it to rotate incredibly smoothly at very low speedsideal for high-quality finishing or coating applications.
Tough Environmental Seals: It features an IP65 rated body and an oil seal with a protective lip, allowing it to function reliably in environments where it might be exposed to cutting oil or fine dust.
Compact 40mm Frame: Despite being a "High Inertia" motor, it maintains a small 40mm square flange, allowing it to provide high stability in very narrow machine footprints.
6000 RPM Capability: While its rated speed is 3000 RPM, it can function at up to 6000 RPM for short bursts, giving you flexibility for fast machine "reset" movements.

Optimal for Industrial Machinery

Designed specifically for industrial machinery, the Panasonic A6 50W Motor excels in demanding environments where reliability and consistency are crucial. Its robust construction ensures dependable power while accommodating the needs of automation and process control systems.

Lightweight Yet Durable Construction

Constructed from high-quality aluminum, this motor remains lightweight at 1.1 kilograms, enabling flexible installation without sacrificing durability. The material not only makes it easy to handle but also optimizes thermal management, which extends operational life.

Three-Phase Efficiency

Operating on a three-phase system, the motor guarantees efficient and stable performance, making it ideal for integration into complex industrial setups. This feature supports both energy savings and consistent output during long production cycles.

FAQ's of MHMF5AZL1U2M Panasonic A6 50W Motor , Torque Nm -0.16, RPM - 3000:

Q: How is the Panasonic A6 50W Motor typically used in industrial settings?

A: The Panasonic A6 50W Motor is primarily used for driving industrial machinery, such as automation systems, conveyors, and process equipment, where precision, durability, and stable output are required.

Q: What are the key benefits of using this motor?

A: Its key benefits include reliable three-phase power delivery, high-speed operation at 3000 RPM, lightweight construction from aluminum, and suitability for demanding industrial environments. The included 1-year warranty adds further peace of mind.

Q: When should I consider installing this motor in my machinery?

A: This motor is ideal for situations where compact size, moderate power (50W), and high RPM are needed. It should be considered when refurbishing or upgrading industrial machines that require efficient and consistent motion control.

Q: Where can I install the Panasonic A6 50W Motor?

A: It can be installed in various industrial equipment within production lines, automation systems, or anywhere a reliable three-phase motor is needed for smooth operation. Its lightweight build allows for versatile mounting options.

Q: What is the process of integrating this motor into existing systems?

A: Integration generally involves connecting the three-phase wiring, aligning the mounting brackets appropriate for your application, and ensuring the motor is programmed or controlled according to the specific operational requirements of your machinery.

Q: How does the aluminum construction benefit the motor's performance?

A: Aluminum construction provides corrosion resistance, dissipates heat efficiently, and reduces overall weight, leading to longer operational life and easier handling during installation or maintenance.
