MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000

Send Inquiry

Request To Call Back

MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000

Name: MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000
Brand: Corbital Enterprise
Price: 36200.0 INR
Availability: InStock

Price 36200.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000 Specification

Product Type
Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
0.7 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
24 Hours

About MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000

The

Panasonic MSMF012L1V2M

is a 100W low-inertia AC servo motor from the MINAS A6 series that includes a built-in electromagnetic holding brake. This "V" model is essentially the safety-enhanced version of the 100W motor you just looked at.

Dimensions and Weight (Imperial)

Because of the added brake mechanism, this motor is longer and heavier than the non-brake version:

Weight: 1.54 lbs (0.7 kg)
Length (Excluding Shaft): 4.29 inches (109 mm)
Total Length (Including Shaft): 5.28 inches (134 mm)
Width (Frame Size): 1.57 inches (40 mm)
Height (Frame Size): 1.57 inches (40 mm)

Key Specifications

Rated Output: 100 W
Rated Torque: 0.32 Nm
Rated Speed: 3000 RPM (Max 6000 RPM)
Brake Status: With Holding Brake (24V DC required)
Inertia Type: Low Inertia
Encoder: 23-bit Absolute (8,388,608 pulses/rev)
Protection Class: IP65

Core Function & Features

Vertical Axis Safety: The primary function of the "V" variant is the holding brake. It locks the shaft when power is cut, preventing a Z-axis (vertical) load from falling and damaging your machine.
Rapid Acceleration: Being a low-inertia motor, it is designed for ultra-fast movements, perfect for high-speed packaging or sorting.
Absolute Position Retention: It remembers its exact location even after a power failure, so you don't need to perform a "homing" sequence.
High Environmental Resistance: Features an IP65 rated body with an oil seal to protect against dust and liquid splashes.

The Panasonic MSMF012L1V2M is a high-performance 100W Low Inertia motor designed specifically for speed and safety. Its functions focus on rapid movement and protecting your machine during power loss.

Primary Functions

Safety Holding (Vertical Axis): The core function of this "V" model is its built-in electromagnetic brake. In the event of a power failure or emergency stop, it physically locks the motor shaft to prevent a vertical load (like a machine head) from falling due to gravity.
Ultra-Fast Acceleration: As a Low Inertia motor, its primary job is to reach its 3000 RPM rated speed (and 6000 RPM max speed) almost instantly. This is essential for high-speed pick-and-place or sorting tasks.
Absolute Position Tracking: It functions as an Absolute system thanks to its 23-bit encoder. It "knows" its exact position at all times. If the machine is turned off and the shaft is moved manually, it will still show the correct position when turned back onno homing required.
Vibration Suppression: It functions with the A6 driver to "detect" the natural vibration of your machine's frame. It then automatically adjusts its torque to cancel out that vibration, allowing for faster movements without the machine shaking.

Key Operational Features

Pinpoint Accuracy: With over 8 million pulses per revolution, it can perform movements so small they are invisible to the naked eye, ideal for semiconductor or medical device assembly.
Heat & Friction Management: The A6 series functions with advanced algorithms that compensate for mechanical friction, ensuring the motor doesn't work harder than necessary and stays cool during high-duty cycles.
Fail-Safe Engagement: The brake is "normally-closed," meaning it is always locked until you apply 24V DC to release it. This ensures the machine is safe even if a cable is accidentally cut.

Reliable Performance for Industrial Applications

This Panasonic A6 100W Motor is engineered to power diverse types of industrial machinery. Its robust three-phase construction coupled with a built-in brake feature ensures stable and precise operation in demanding environments, making it a preferred choice for automation and equipment upgrades.

Lightweight and Durable Design

Weighing just 0.7 kilograms, this motor utilizes premium aluminum construction for longevity and ease of installation. The compact design fits seamlessly into many industrial setups, reducing downtime and maintenance requirements.

1-Year Warranty for Peace of Mind

Each MSMF012L1V2M motor comes with a full 1-year warranty, offering added security to end users. Support is provided by authorized suppliers, traders, and wholesalers, ensuring quick response to warranty-related queries or issues.

FAQ's of MSMF012L1V2M Panasonic A6 100W Motor + BRK , Torque Nm -0.32, RPM - 3000:

Q: How is the MSMF012L1V2M Panasonic A6 motor installed in industrial machinery?

A: The motor is designed for easy integration with most industrial systems, thanks to its lightweight aluminum build and compact dimensions. It can be mounted using standard industrial hardware and connected to a three-phase power supply.

Q: What are the primary benefits of using this specific Panasonic 100W motor?

A: This motor delivers stable torque (0.32 Nm) at high speeds (3000 RPM), ensuring reliable and efficient operation. Its aluminum construction, lightweight design, and integrated brake provide added safety and durability, ideal for demanding industrial environments.

Q: When should I consider replacing or upgrading to the MSMF012L1V2M motor?

A: Upgrade or replacement is ideal when existing motors lack required torque, experience frequent breakdowns, or fail to meet the speed demands of your machinery. This Panasonic model is ideal for applications requiring a three-phase, high-efficiency solution.

Q: Where can I purchase the MSMF012L1V2M motor and obtain after-sales support?

A: The motor is available through authorized suppliers, traders, and wholesalers specializing in industrial equipment. These channels also provide after-sales support, including warranty claims and technical assistance.

Q: What is the process for claiming the 1-year warranty on this Panasonic motor?

A: To activate or claim the warranty, contact your supplier or authorized Panasonic distributor with proof of purchase and product serial number. They will guide you through troubleshooting, repair, or replacement steps if necessary.

Q: Is this motor suitable for continuous usage in heavy-duty industrial settings?

A: Yes, its robust design, high RPM, and dependable torque output make it suitable for continuous or repetitive use in a wide range of industrial machinery, ensuring long-term reliability.

Q: How does the motor's integrated brake enhance its operational safety?

A: The built-in brake provides rapid stopping capability, adding an extra layer of safety to machinery operations. This feature helps prevent unwanted motion or accidents during operation or maintenance.
