VSR23-9p5 - Crompton VFD - 2.2 kW / 3HP 1-Phase 220V Solar

Get a Price/Quote

MOQ : 1 Number

VSR23-9p5 - Crompton VFD - 2.2 kW / 3HP 1-Phase 220V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Weight
1.5 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
1 Phase

Material
Polycarbonate

VSR23-9p5 - Crompton VFD - 2.2 kW / 3HP 1-Phase 220V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSR23-9p5 - Crompton VFD - 2.2 kW / 3HP 1-Phase 220V Solar

The Crompton Greaves Emotron VSR23-9P5 is a 2.2 kW (3 HP) Solar Variable Frequency Drive (VFD) configured for a 220V single-phase grid input or direct solar array DC voltage. Because it is built on the exact same Frame Size 2 (VSS2) hardware housing platform as the previous 2.2 kW and 1.5 kW models, its physical sizing remains completely unchanged. [1, 2, 3]

Physical Specifications (Inches & Lbs)

Height: 173 mm (6.81 inches)
Width: 110 mm (4.33 inches)
Depth / Length: 135 mm (5.31 inches)
Total Weight: 1.5 kg (3.31 lbs) [, 2, 3]

Technical & Electrical Differences (VSR11 vs. VSR23)

While the outer physical dimensions match the 110V version (VSR11-9P5) precisely, the internal electrical configuration of this 220V model changes how you set up your solar array:

Grid/Generator AC Input Voltage: 220V to 240V AC Single-Phase (as opposed to 110V on the VSR11).
Maximum Solar DC Input Voltage: Up to 400V DC (Allows you to wire more solar panels together in a single serial string).
Recommended MPPT Voltage Range: 250V to 350V DC (The sweet spot where the drive extracts peak daily water output).
Recommended Solar Array Power: 3.3 kWp (Kilowatt-peak) to comfortably handle motor start-up surges.
Max Output Current: 9.5 Amps to drive standard 3-phase 220V AC water pump motors. [1, 2, 5]
