ECMA-EA1310RS Delta Servo Motor 1000W M , Torque Nm - 4.77 , RPM - 2000

Name: ECMA-EA1310RS Delta Servo Motor 1000W M , Torque Nm - 4.77 , RPM - 2000
Brand: Corbital Enterprise
Price: 31800.0 INR
Availability: InStock

Price 31800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-EA1310RS Delta Servo Motor 1000W M , Torque Nm - 4.77 , RPM - 2000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
6.5 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-EA1310RS Delta Servo Motor 1000W M , Torque Nm - 4.77 , RPM - 2000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-EA1310RS Delta Servo Motor 1000W M , Torque Nm - 4.77 , RPM - 2000

The Delta ECMA-EA1310RS is a 1.0 kW Medium Inertia AC servo motor. As an "EA" series model, it features a 17-bit absolute encoder, which means it "remembers" its position even after a power cut, so you don't have to home the machine every time you turn it on.

The "RS" suffix indicates this model has a keyway and oil seal but NO brake. Its built for heavy-duty horizontal movements where you need more stability than a low-inertia motor can provide.

Physical Specifications

This motor uses a 130 mm frame to accommodate the higher torque of the medium-inertia rotor.

Attribute	Metric Value	Inches / US Units
Height (Frame)	130 mm	5.12 in
Width (Frame)	130 mm	5.12 in
Length (L)	158 mm	6.22 in
Weight	6.5 kg	14.33 lbs

Key Technical Data

Rated Torque: 4.77 Nm (Peak 14.32 Nm).
Rated Speed: 2000 RPM (Max 3000 RPM).
Shaft Diameter: 22 mm (0.87 in).
Protection: IP65 rated (dust-tight and splash-resistant).
Resolution: 131,072 pulses per revolution (17-bit).

Function

Stability for Large Loads: The "Medium Inertia" design makes it the best choice for machines with large mechanical parts (like heavy gantry systems), as it prevents the motor from vibrating or overshooting.
Absolute Accuracy: Since its an absolute motor, it provides highly precise positioning data directly to the ASD-A2-1021-M or ASD-A2-1023-M drive without needing external limit switches for homing.
