MHMF152L1G6M Panasonic A6 1500W Motor , Torque Nm - 7.16, RPM - 2000

Price 56100.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MHMF152L1G6M Panasonic A6 1500W Motor , Torque Nm - 7.16, RPM - 2000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinery

Color
Black and Silver

Weight
6.7 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

MHMF152L1G6M Panasonic A6 1500W Motor , Torque Nm - 7.16, RPM - 2000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MHMF152L1G6M Panasonic A6 1500W Motor , Torque Nm - 7.16, RPM - 2000

Specification Function , Weight , Lenth And Width And Hight In Inch..

The Panasonic MHMF152L1G6M is a 1500W (1.5 kW) High-Inertia AC servo motor from the MINAS A6 family. While it shares the same power and torque ratings as the MDMF (Middle-Inertia) series, the MHMF series is specifically designed for applications requiring the highest level of mechanical stability. [1]

Function

High-Inertia Stability: Its primary function is to provide stable motion for machinery with very large mechanical loads or high load-inertia ratios. The heavier internal rotor prevents "oscillation" or vibration that can occur when using a lighter motor on a heavy machine.
Precision Control: Equipped with a 23-bit absolute/incremental encoder (8.38 million pulses per revolution) for extremely fine positioning accuracy.
High Torque Performance: Provides a robust 7.16 Nm of continuous torque, making it suitable for heavy-duty applications like large CNC gantries or material handling robots. [1, 2, 3, 4]

Technical Specifications

According to data from Panasonic Industry and industrial distributors, the specifications are:

Feature [1, 2, 3]	Specification
Rated Output	1500 W (1.5 kW)
Rated Torque	7.16 Nm
Peak Torque	21.5 Nm
Rated Speed	2000 RPM
Max Speed	3000 RPM
Voltage	200 V AC
IP Rating	IP67 (Dust-tight and water-resistant)
Brake	Without holding brake
